Blue Giant EPT-33-4W Manual Pallet Truck

Details

The EPT-33-4W Manual Pallet Truck is designed to handle four-way pallets and offers a 220-degree steer arc for excellent maneuverability in tight locations. Each unit comes with a polyurethane steer wheel and steel load rollers for easy travel.

Equipment Type
Forklifts / Pallet Trucks

Capacity:
3,300 lbs (1,497 kg)

Lowered Fork Height:
2″ (51 mm)

Raised Fork Height:
5.5″ (140 mm)

Fork Length:
48″ (1,219 mm)

Fork Width:
6″ (152 mm)

Overall Fork widths:
33″ (838 mm)

Turning Radius:
52.5″ (1,334 mm)

OPERATION

  • 200 degree operational arc
  • Requires eight full strokes to reach maximum elevated height of 5.5″ (138 mm)
  • Control handle has three position (raise/neutral/lower) fingertip control. Ergonomically designed and free of pinch points
  • Spring loaded handle returns to upright position automatically
  • Comfort grip handle
  • 2″ (51 mm) lowered fork height
  • Polyurethane steer wheel and steel load rollers
  • Features a powder coat paint and robotic welds throughout

HYDRAULICS

  • Galvanized hydraulic pump includes an overload relief valve and braking can be actuated by both hand and foot controlled release

FORKS / CHASSIS

  • 33″ (838 mm) wide forks
  • Tapered forks and entry and exit rollers allow for smooth pallet handling
  • Helper rollers for easy exit and entry of pallets
  • Rugged heavy duty frame
  • Adjustable push rods allow for individual adjustment capability
  • Hangers are constructed of cast iron for greater strength and longevity
