JLG AE1932 Scissor Lift
Details
Zero leaks. Zero emissions. Low noise. Experience clean operation and reduced maintenance with our JLG AE1932 DaVinci all-electric scissor lifts.
The new industry benchmark—the DaVinci Series AE1932—is a fully electric scissor lift that has zero hydraulic components, which means you experience zero leaks. Its electric driveline components contribute to a 70% decrease in power consumption, enabling this machine to do more work while consuming less energy. The lower energy consumption also allows this lift to use a single, maintenance-free battery that lasts the life of the machine. Thanks to advanced onboard technology, you can use your smartphone for service and diagnostics. Experience remote diagnostics, remote software updates and a host of additional features that improve the reliability and durability of this unit. With almost no preventative maintenance requirements—the future is here.
Key Specs
- Platform Height: 19 ft / 5.79 m
- Platform Capacity: 606 lb / 274.88 kg
- Machine Width: 2 ft 8 in. / 0.81 m
- Drive Speed – Platform Lowered: 4 mph / 6.44 km/h
Key Features
- Improved Cost of Ownership: This model sets a new industry benchmark with almost no maintenance, with a new diagnostic and analyzer tool that can be used on any smart device
- Longer Battery Life: Class-leading, single lithium ion battery lasts the life of the machine
- Faster Charging: Quick charge in five minutes for 100 ft of drive plus enough torque for loading
- Equipment Type
- Aerial Lifts / New Scissor Lifts
Batteries:
Single 24V Lithium Ion, 72Ah
Charger:
27 amp
Machine Weight:
3450 lb / 1564.89 kg
Drive Speed – Platform Elevated:
0.5 mph / 0.80 km/h
Drive Speed – Platform Lowered:
4 mph / 6.44 km/h
Drive System:
24V AC
Grade-ability:
25 %
Lift Time:
24 sec.
Lower Time:
26 sec.
Maximum Drive Height:
19 ft / 5.79 m
Platform Capacity:
606 lb / 274.88 kg
Platform Capacity – Extension:
265 lb / 120.20 kg
Turning Radius – Inside:
0 in. / 0 m
Turning Radius – Outside:
5 ft 6 in. / 1.68 m
Ground Clearance:
3 in. / 0.07 m
Machine Height:
6 ft 11 in. / 2.1 m
Machine Height – Rails Folded:
5 ft 4 in. / 1.63 m
Machine Length:
5 ft 9 in. / 1.74 m
Machine Width:
2 ft 8 in. / 0.81 m
Platform Extension Length:
3 ft / 0.91 m
Platform Height – Lowered:
3 ft 3 in. / 0.98 m
Platform Railing Height:
3 ft 8 in. / 1.13 m
Platform Size:
25.4 in x 62.7 in
Platform Height:
19 ft / 5.79 m
Working Height:
25 ft / 7.62 m
- Improved Cost of Ownership: This model sets a new industry benchmark with almost no maintenance, with a new diagnostic and analyzer tool that can be used on any smart device
- Longer Battery Life: Class-leading, single lithium ion battery lasts the life of the machine
- Faster Charging: Quick charge in five minutes for 100 ft of drive plus enough torque for loading
- Smoother Operation: Efficient AC drive motors provide 4 mph stowed drive speed, while independent wheel motor control reduces tire wear and limits damage to sensitive flooring
- Increased Efficiency: Fully electric and highly efficient for zero emissions and zero leaks
- ANSI A92.20 Compliance: Load sensing system, self-closing gate and QuikFold rail system
