Combilift COMBI-CS Forklift Combilift

Details

Equipped with our patented multi-position tiller arm the Combi-CS offers safer operation, maximum operator visibility and narrow aisle performance.

Safety was a chief consideration for the Combi-CS. The multi-position tiller enables push-button rotation of the rear wheel, allowing the operator to remain in the safest possible position when placing and picking in narrow aisles, which is at the side of the unit. This improves forward visibility and greatly reduces the risk of incidents in tight confines. This and its excellent ergonomics make it easy and stress-free to operate

Equipment Type
Forklifts / Pallet Movers

  • AC Electric Pump Motor:
    24 V / 6.7 HP

  • AC Electric Traction Motor:
    24 V / 3.35 HP

  • Battery Capacity:
    24 V / 330 Ah

  • Capacity:
    2200 lbs

  • Fork Backward Tilt:
    5°

  • Fork Forward Tilt:
    2°

  • Fork Section:
    1 ½" x 4" x 37 ½"

  • Front Tire (Polyurethane):
    OD 6" / Width 2"

  • Gradeability:
    5%

  • Ground Clearance to Center of Wheelbase:
    2"

  • Ground Clearance Under Mast:
    3"

  • Height Mast Closed:
    72"

  • Length From Face of Fork:
    41”

  • Load Center Distance:
    20"

  • Max. (Mast raised):
    124"

  • Max. Lift Height:
    98"

  • Maximum Ground Speed:
    4 mph

  • Minimum Outside Radius:
    38"

  • Outside Spread of Fork Arms :
    24 ½"

  • Overall Length:
    79”

  • Overhang Back:
    7"

  • Overhang Front:
    40 ¾"

  • Rear Tire (Vulkollan):
    OD 10" / Width 3"

  • Standard Color:
    Yellow & Gray

  • Track Front:
    29"

  • Unladen Weight:
    5060 lbs

  • Wheelbase:
    31”

  • Width:
    35"

  • Rear Wheel Drive
  • Patented Multi-Position Tiller Arm
  • AC Motor Technology
  • Power Steering
