Combilift COMBI-CB8 Forklift Combilift

Details

The innovative and compact Combi-CB is designed to increase productivity, improve safety and help increase your storage capacity both indoors & outdoors.This unit is suitable for handling guided aisles, long loads, narrow aisles, and palletised goods.

Equipment Type
3 Wheel Electric Forklift Trucks / Forklifts

  • 20 x 9 x 16 Front Tire x 2 (Solid Rubber):
    OD 21” / Width 9”

  • 28 x 12.5 – 15 Rear Tire x 1 (Super Elastic):
    OD 28” / Width 12.5”

  • 3ltr GM LPG:
    65 HP

  • Approach Angle:
    30°

  • Backward Tilt:
    5°

  • Capacity:
    8,000 lbs

  • Departure Angle:
    30°

  • Electrics:
    12 V

  • Fork Section:
    6" x 2 " x 42"

  • Forward Tilt:
    3°

  • Free Lift Height :
    0"

  • Gradeability:
    10%

  • Ground Clearance to Wheelbase Center :
    6"

  • Ground Clearance Under Mast:
    6"

  • Height Mast Closed :
    114"

  • Height of Overhead Guard:
    92.75"

  • Length From Face of Fork :
    72"

  • Load Center Distance:
    24"

  • Max. (Mast raised) :
    198.75"

  • Maximum Ground Speed:
    8 mph

  • Minimum Outside Radius:
    66"

  • Outside Spread of Fork Arms:
    59"

  • Overall Length:
    114"

  • Overhang Back :
    6"

  • Overhang Front:
    13"

  • Ramp Angle:
    28°

  • Standard Color:
    Green and Gray

  • Standard. Lift Height :
    159"

  • Track Front:
    55"

  • Unladen Weight:
    16,700 lbs

  • Wheel Base :
    53.25"

  • Width:
    64"

  • 4 Way Lever Positioning of Wheels
  • Curtis AC Software
  • Rubber mounted cabin
  • AC Motor Technology
  • Load Sensing Steering
  • 2 Wheel Drive
  • Multi-Directional Operation
