Combilift 12,000 4WSL Sideloader Forklift Combilift Equipment Inventory

Details

The 4 wheel Sideloader forklift designed for the safe, space saving and productive handling of long and bulky loads.

Equipment Type
Forklifts / Very narrow aisle

  • Backward Tilt:
  • Capacity:
    12,000 lbs
  • Deutz TCD 3.6 / 4.3 ltr GM LPG:
    76 HP/ 100 HP
  • Electrics:
    12 Volt
  • Fork Section :
    2” x 7 ¾” x 55”
  • Forward Tilt:
  • Frame Opening:
    55”
  • Freelift Height:
    0”
  • Gradeability:
    15%
  • Ground Clearance to Center of Wheelbase:
    16”
  • Ground Clearance Under Mast:
    12”
  • Height Mast Closed:
    119 ½”
  • Height Over Cab (Without work lights):
    107”
  • Length:
    182 ¼”
  • Length From Face of Fork :
    31 ½”
  • Load Center Distance:
    23 ½”
  • Mast Travel:
    57”
  • Max. (Mast raised):
    203”
  • Max. Lift Height:
    159”
  • Maximum Ground Speed:
    16 mph
  • Minimum Outside Radius:
    165”
  • Outside Spread of Fork Arms:
    50 ¾”
  • Overall Width:
    86”
  • Overhang Back:
    31 ½”
  • Overhang Front:
    15 1/4”
  • Platform Height:
    37 ½”
  • Platform Length:
    55”
  • Pneumatic / Super Elastic Front Tire:
    300 – 15
  • Standard Color:
    Yellow & Gray
  • Suspension Seat:
    KAB Model 116
  • Track :
    63 ¼”
  • Unladen Weight:
    16,975 lbs
  • Wheelbase:
    104 ¾”
  • Hydraulic Oil Cooler
  • 2 Wheel Drive
  • Tilting Chassis
  • Hydraulic Suspended Cabin
  • Wet Disc Brakes
  • Load Sensing Steering
