Details

The Combi-MG Mobile Gantry is the perfect solution for handling and conveying extremely large loads typical of industries such as shipping, aerospace, wind turbine, large scale civil industry, precast concrete and large scale structural steel industries.

Equipment Type
Forklifts / High Capacity

  • Overall Length:
    29′ 6″
  • Overall Width:
    16′ 9″
  • Overall Height:
    17′ 6″
  • Ground Clearance Under Side Section:
    9 ½″
  • Height Over Engine:
    80 ½″
  • Wheelbase:
    151 ½″
  • Width Load Area:
    227 ½″
  • Height Load Area:
    127″
  • Minimum Outside Radius:
    181″
  • Lift Stroke:
    47 ½
  • Capacity:
    44,000 kg – 200,000kg
  • Unladen Weight:
    29,000 lbs.
  • Gradability:
    5% fully loaded
  • Maximum Ground Speed:
    4 mph
  • V3800 Kubota Diesel Engine:
    96 HP
  • Electrics:
    12 V
  • Tires:
    4 x Super Elastic Puncture Proof Tires
  • Standard Color:
    Yellow & Gray
  • Rubber Mounted Half Open Cabin
  • 3 Wheel Hydrostatic Drive
  • Load Sensing Steering
  • 4 Way Lever Positioning of Wheels
  • Hydraulic Oil Cooler
