JLG ES1932 Scissor Lift
Details
Experience the benefits of reduced charging time and longer runtime with the JLG ES1932 scissor lifts. These electric slab scissors are designed so you have fewer scheduled services, a quieter work area, less dependency on hydraulic oils and zero emissions. With the latest technology built in, these JLG ES1932 electric scissor lifts deliver innovative features that boost operator confidence. Increase your productivity and enhance safety on the job when you choose an electric man lift from JLG.
Key Specs
- Platform Height: 19 ft / 5.79 m
- Platform Capacity: 507 lb / 229.97 kg
- Machine Width: 2 ft 8 in. / 0.81 m
- Drive Speed – Platform Lowered: 3 mph / 4.83 km/h
Key Features
- Increased Battery Life: Refreshed design includes electric drive, which delivers up to double the battery life of a standard scissor
- Time Savings: Standard QuikFold rail system allows operators to fold the rails in a fraction of the time of a standard machine
- Simplified Use & Service: Standard USB charger and phone holster improve the operator experience, while a high degree of commonality with other JLG® scissors simplifies service
- More Options: Available as an indoor-only option (ES1932i)
- Equipment Type
- Aerial Lifts / New Scissor Lifts
Batteries:
4 x 6V 220 amp-hour
Charger:
27 amp Universal Algorithm
Machine Weight:
3450 lb / 1564.89 kg
Drive Speed – Platform Elevated:
0.5 mph / 0.80 km/h
Drive Speed – Platform Lowered:
3 mph / 4.83 km/h
Drive System:
24V DC
Grade-ability:
25 %
Lift Time:
27 sec.
Lower Time:
28 sec.
Maximum Drive Height:
19 ft / 5.79 m
Platform Capacity:
507 lb / 229.97 kg
Platform Capacity – Extension:
265 lb / 120.20 kg
Turning Radius – Inside:
0 in. / 0 m
Turning Radius – Outside:
5 ft 6 in. / 1.68 m
Ground Clearance:
3 in. / 0.07 m
Machine Height:
6 ft 11 in. / 2.1 m
Machine Height – Rails Folded:
6 ft 6 in. / 1.99 m
Machine Length:
5 ft 9 in. / 1.74 m
Machine Width:
2 ft 8 in. / 0.81 m
Platform Extension Length:
3 ft / 0.91 m
Platform Height – Lowered:
3 ft 3 in. / 0.98 m
Platform Railing Height:
3 ft 8 in. / 1.11 m
Platform Size:
25.4 in x 62.7 in
Platform Height:
19 ft / 5.79 m
Working Height:
25 ft / 7.62 m
