Advance Advenger Scrubber

Adjustable steering:
Included

Body height:
51.7 in (131 cm)

Body length:
60 in (152 cm)

Body width:
27.5 in (70 cm)

Brush motor hp (W):
0.64 hp (480 W)

Brush speed (RPM):
2,250 RPM

Built-in squeegee hanger:
Included

CFM:
66 @ 2 in (5 cm) orifice

Cleaning path:
28 in

Drive motor hp (W):
1.05 hp (780 W)

Ecoflex installed:
Included

Gradeability – Cleaning:
9% (5 degrees)

Gradeability transport % (DEG):
16% (9 degrees)

High flow rate:
0.4 / 0.8 gal/min (1.65 / 3.03 L/min)

Large recovery tank opening:
Included

Low flow rate:
0.1 / 0.2 gal/min (0.38 / 1.51 L/min)

Low step for easy on/off:
Included

Max. cleaning speed:
3.12 mph (4.8 kph)

Max. coverage per hour @ 3.12 MPH:
39,424 sq ft (3,663 sq m)

Max. PSI:
175 PSI (12.3 kg/sq cm); (Full tank and 200 lb rider)

Max. shipping weight:
1,400 lb (635 kg)

Max. transport speed mph (km/h):
3.91 mph (6.3 kph)

Max. weight (full solution tank and largest batteries):
1,451 lb (658 kg)

Max. weight w/o batteries:
536 lb (244 kg)

Max. width w/o squeegee:
31 in (79 cm)

Medium flow rate:
0.2 / 0.4 gal/min (0.76 / 1.51 L/min)

Min. aisle turn (cm):
63 in (160 cm)

Model No:
56601897

Non marking traction wheels:
Included

Open machine design:
Included

Power source:
24 VDC

Productivity per tankful:
140 mins (scrubbing) / 280 mins (Floor Finish Removal)

Recovery tank capacity gal (l):
29 gal (110 L)

Refillable cartridges:
Included

REV™:
Included

Scrub head type:
REV™ Dual Random Orbit

Scrub pressure – extreme scrub:
175 lb (79 kg)

Scrub pressure – heavy scrub:
125 lb (57 kg)

Scrub pressure – regular scrub:
80 lb (36 kg)

Sealed waterlift:
63 in H2O (15.7 kPa)

Solution tank capacity gal (l):
28 gal (106 L)

Sound pressure level (dB(A)):
63.7 dB A (IEC 60704-1/ISO 11201)

Squeegee width:
32.6 in (83 cm)

Vacuum motor:
0.75 hp (560 W)
